Terex TC80

CONVEYOR
ENQUIRE NOW CALL US
OVERVIEW

The Terex TC80 is a tracked mobile conveyor. It carries crushed or screened material away from a plant and builds stockpiles, removing the need for a wheel loader to shuttle material between machines.

Team Engineers Advantage
20+
Years
4,500+
Machines
24/7
Support
100%
Genuine Parts
Overview Specifications
Technical Specifications

Terex TC80 Full Specs

TECHNICAL SPECIFICATION
DESCRIPTIONSPECIFICATION
Conveyor Length22.8m
Belt Width1050mm
Max Discharge Height @ 25°10.41m
CapacityUp to 500 tph
Belt TypePlain - 3 Ply
Powerunit (Tier 3)Deutz DT011 36kW
Powerunit (Tier 4F)Deutz TD2.9 45kW
Powerunit (Stage V)Deutz TC 2.9 L4 45kW
Drive Drum Diameter286mm
Feedboot Capacity (Standard)0.6m³
Feedboot Capacity (Extended)1.6m³
Feedboot Capacity (Biomass Option)5.24m³
Track Shoe Width400mm
Track Sprocket Centers4000mm
Track Speed0.9km/h
Fuel Tank Volume200L
TRANSPORT DIMENSIONS
DESCRIPTIONSPECIFICATION
Length11.88m
Width2.25m
Height2.88m
Weight16,750kgs
Containerised shipping40ft x 9ft 6in High Cube Container

Image illustration only. Production machines may differ in appearance and features vary between markets and models.
